Carbide CNC Two Flute Spiral Router Bit

3.175*17mm Carbide CNC Two Flute Spiral Bits for Cutting Router End Mill CUTTER – 2LX3.17

Product Description:
Spiral bits combine a shearing action in cutting with an augering action in chip clearance. The shearing action yields an especially clean & accurate cut, while the augering action clears chips from the cut. The “down-cut” cuts from the surface down, leaving a smooth edge at the surface.

By using Two/Double Flute Straight Router bit, cutting the below material becomes an easy job for you.
All composition materials, plywood, hardwood and soft wood
PVC, plastic board
Acrylic, double color plate, ABS, brass, aluminum etc.

Specification:
Cutting Edge Diameter-CED: 3.175mm
Cutting Edge Length-CEL: 17mm
Shank Diameter-SD: 3.175mm
Over Length-OVL: 38mm
