GY-521 MPU6050 3 Axis Analog Gyro 3 Axis Accelerometer Sensors Module

GY-521GY-521 MPU-6050 6DOF Module 3 Axis Analog Gyro Sensors 3 Axis Accelerometer Module

Product Description:
MPU-6000 is the world’s first integrated 6-axis motion processing components, compared to the multi-component programs, eliminating the problem of the difference between the combination when the axis of the gyroscope and accelerometer, reducing the amount of packaging space. MPU-6000 integrated 3-axis gyroscope, three-axis accelerometer, and containing other brands of the accelerator by the second I2C port connection, magnetic sensors, or other sensors of digital motion processing (DMP: Digital Motion Processor) hardware acceleration engine, by the main I2C port in the form of a single data stream output to the application side, complete 9-axis fusion algorithm technology

InvenSense’s motion processing database, to deal with the complexity of the motion sensing data, to reduce motion processing computation load on the operating system, and the architecture of the API for application development.

MPU-6000 angular velocity grid sensing range is 250, 500, 1000 and 2000 / sec (dps), can accurately chase 2000 and 2005, fast and slow action, and the user can program to control the accelerator grid flu The measurement range of 2g, 4g 8g and 16g. Product transfer through the I2C up to 400kHz up to 20MHz SPI.

MPU-6000 to work under different voltage VDD supply voltage of 2.5V 5% referral 3.0V 5% or 3.3V 5%, logical interface VVDIO power supply of 1.8V 5%. MPU-6000 package size 4x4x0.9mm (QFN), is revolutionary in the industry size. Other features include a built-in temperature sensor oscillator contains only 1% change in the operating environment.

1.Use the chip: MPU-6050
2.Power supply: 3-5v (internal low dropout regulator)
3.Communication modes: standard IIC communications protocol
4.Chip built-in 16bit AD converter, 16-bit data output
5.Gyroscope range: 250 500 1000 2000 /s
6.Acceleration range: 2 4 8 16g
7.Immersion Gold PCB machine welding process to ensure quality
8.Pin pitch: 2.54mm

Code Example

Package included:
1 MPU6050 6DOF Module 3 Axis Analog Gyro Sensors
