BC-7-3P Battery Connector

BC-7-3P Battery 3P Battery Connector Mobile Phone Battery Holder Spring type Battery Connector

Product Description:
Planarity of signal solder tail signal from Z
Upper direction: 0 maximum
Lower direction: 0.10mm maximum
Current rating: 2.0A maximum
Voltage rating: 12V
Dielectric withstanding voltage: 250V AC R. M. S
Insulation resistance: 1, 000M ohms minimum at 500V DC
Operating temperature: -30 to +85º C
Durability: 5,000 cycles
Operating force of pin: 140gf + – 20g/each
Stroke: 1.2mm.
