GY-65 BMP085 I2C Digital Barometric Pressure Sensor Module

GY-65Atmospheric pressure module altimeter module BMP085 module GY – 65

Product Description:
BMP085 is in a high precision, low energy consumption of pressure sensor, can be applied in mobile devices. Its performance is remarkable, the minimum absolute accuracy can reach 0.03 hPa, and very low power consumption, only 3 μ A. BMP085 using powerful 8 – pin ceramic leadless chip load (LCC) of ultra-thin packaging, can through the I2C bus directly with all kinds of microprocessor connected.

Main features:
Pressure range: 300-1100 hpa (elevation 9000 meters to 500 meters)
Power supply voltage: 1.8 V – 3.6 V (VDDA)
1.62 V – 3.6 V (VDDD)
LCC8 packaging: lead-free ceramics carrier package (LCC)
Feet inches: 5.0 mmx5.0 x1.2 mm
Low power consumption: 5 μ A in the standard model
High precision, low power consumption mode, resolution is 0.06 hPa (0.5 meters)
High linear mode, resolution is 0.03 hPa (0.25 meters)
Including temperature output
The I2C interface
Temperature compensation
Lead-free, meet the RoHS standard,
Response time: 7.5 ms
Standby current: 0.1 u A
No external clock circuit

Typical application:
GPS precise navigation (air a prediction, and the upper and lower bridge detection, etc.)
Indoor and outdoor navigation
Leisure, sports and health monitoring
The weather forecast
Vertical speed indicator (up/sinking speed)
Fan power control

Download Library

Package includes:
1 BMP085 Sensor Module
