Stepper Motor + Driver Board ULN2003

5V 4-phase Stepper Motor + Driver Board ULN2003

Product Description:
Rated Voltage: DC5V
4-phase
Reduction Ratio: 1/64
Step Torque Angle: 5.625/64
DC Resistance: 200Ω±7% (25)
Insulation Resistance: >10MΩ (500V)
Dielectric Strength: 600V AC / 1mA / 1s
Insulation Grade: A
No-load Pull in Frequency: >600Hz
No-load Pull out Frequency: >1000Hz
Pull in Torque: >34.3mN.m(120Hz)
Detent Torque: >34.3mN.m
Temperature Rise: <40K(120Hz)
Noise: Board Size: Approx. 29 ×21 mm

Example code

Package list:
1 Stepper motor
1 ULN2003 Driver board
